Description
-
Number of Teeth:
9
-
Position/Degree:
links
-
Rotation Direction:
Clockwise rotation
-
Starter Type:
Self-supporting
-
Number of mounting bores:
3
-
Connecting Angle [Degree]:
60
-
Fastening hole angle measurement [Degree]:
60
-
Bore Ø 2 [mm]:
12
-
Bore Ø 3 [mm]:
12
-
Pinion Rest Position [mm]:
27,5
-
Length [mm]:
293
-
Jaw opening angle measurement [Degree]:
20
-
Bore Ø [mm]:
12
-
Flange Ø [mm]:
110
-
Voltage [V]:
24
-
Rated Power [kW]:
3,2
-
Clamp:
50
Analogs parts
Product
Name
t.availability
Price
Car Name
OE number
DAF
1516715R
IVECO
42498142
FIAT
4691200
LANCIA
4691200
FIAT
4706931
LANCIA
4706931
IVECO
4744811
FIAT
4744841
IVECO
4744841
LANCIA
4744841
FIAT
4752403
LANCIA
4752403
FIAT
4807377
IVECO
4807377
LANCIA
4807377
IVECO
504038038
IVECO
504072485
FIAT
6706931
LANCIA
6706931
FIAT
77050561
LANCIA
77050561
FIAT
77080560
LANCIA
77080560
FIAT
77080561
FIAT
929162
LANCIA
929162
